PW800, Users
Rev O, January, 2008
4
Introduction
This manual contains specifications, operation instructions, and calibration instructions for
Intercomp's model PW800 pallet scale. Troubleshooting tips and a parts and accessories
listing are also included.
Specifications
Controls
Display: 0.8” 5 digit LED (Optional: 5 digit, 1.0 inch LCD)
Indicators: On-screen lb, kg, pieces, gross, net, total, and peak.
Switches: ON/OFF, ZERO, NET/GROSS, MODE, TARE, UNITS/PIECES, TOTAL,
SCALE SELECT, PRESET TARE, SAMPLE, APW, PEAK HOLD,
OVER, UNDER, I.D.#, SET POINT 1, SET POINT 2, PRINT, ENTER,
CLEAR, numeric 10-key.
Light. Automatic in low light
Electrical
Batteries: 9 Nickel-Cadmium D cells or Alkaline.
Battery life: Up to 75 hours with alkaline batteries. Up to 25 hours with
Ni-Cad cells. (LED Display)
Charge Time: 16 Hours
Charger Voltage: 12 to 20 V AC/DC
Charger Current: 250 ma
Charger/Power Supply: 110 VAC or 220 VAC.
Low Battery Shut Off: Unit automatically shuts off if batteries are low.
Auto Shut Off: Shuts off after adjustable time (up to 120 min) without use or
motion.
Sleep mode: Low power mode after adjustable time (up to 120 min)
without use or motion.
Serial Input/Output: RS232 standard. RS485, and TTL optional
Performance
Accuracy:
± 0.1% of applied load or ± display graduation, whichever is greater.
Environmental
Humidity: 10 to 95% Non-Condensing.
Temperature: Operating: -10 C to +40 C. / +14 F to +104 F.
Storage: -40 C to +75 C. / -40 F to +170 F
Physical
Dimensions: (Standard Forks) 48" L x 28" W x 2.9"H /
1219 mm x 711 mm x 74 mm
Weight: 275 lbs/125 kgs
