Switch # Pack A Pack B Pack C
1 OFF OFF See Below
2 ON ON "
3 ON OFF "
4 ON OFF "
5 ON ON ON
6 OFF ON ON
7 OFF ON OFF
8 ON ON OFF
The above switches should be set on switch packs A, B, and C.
Pack C, SW 1 to 4:
Baud Rate C-1 C-2 C-3 C-4
9600 ON ON ON OFF
4800 OFF ON ON OFF
2400 ON ON OFF OFF
1200 OFF OFF ON OFF
600 ON OFF OFF ON
300 OFF ON OFF OFF
150 ON OFF OFF OFF
75 OFF OFF ON ON
The connection to an Intercomp S400 display is:
PW800 S400
2 (TXD) 2 (RXD)
7 (GND) 7 (GND)
The connection to an Intercomp SA2000 display is:
PW800 SA2000
2 (TXD) 3 (RXD)
7 (GND) 7 (GND)
The connection to a 9-pin PC communication port is:
PW800 PC 9-pin
2 (TXD) 2 (RXD)
7 (GND) 5 (GND)
Note: For some setups it may be necessary to jump pins [6, 1, and 4] together, and pins [7 and
8] together on the PC port connector.
The connection to a 25-pin PC communication port is:
PW800 PC 25-pin
2 (TXD) 3 (RXD)
7 (GND) 7 (GND)
Note: For some setups it may be necessary to jump pins [6, 8, and 20] together, and pins [4
and 5] together on the PC port connector.
