Interflex IF-4070 User Manual

Page 19
Technical Specifications
Power Supply
- Mains voltage
230 VAC, +/ - 10%, 50Hz (optionally also 115VAC 60Hz)
- Fuse protection
250mA, slow-blowing fuse type TR5 (48-1007)
(500mA, slow-blow fuse type TR5 for devices with 110 VAC)
- Power consumption
approx. 16VA
- Low-voltage (optional):
12 to 30VAC/VDC, recommended 18VAC/DC
- PoE (Power over Ethernet)
With devices of power class 3.
- Internal emergency power supply
(optional)
Accumulator bridging period approx. 25 minutes
Interfaces
- Interfaces to host PC
Ethernet as per IEEE 802.3 TCP/IP
- Serial interfaces
RS232 or RS485 with 9600 Bd (1200 Bd., 19200 Bd.
possible)
- Interfaces to slave terminals
3x RS485, with 9,600 baud or 19,200 baud (19,200 default
setting)
- Interfaces for service
Ethernet with TELNET or SSH, RS232 with 115200 baud
Inputs
8 input contacts for floating sensors. Debounce time of
contacts at least 100 ms.
Output relay/ switching power
8 relays with 'normally closed’ (NC) and 'normally open’
(NO) contacts 30 V, 2 A maximum switching power
Operating status indicators
7 LEDs on front side
General data:
- Ambient temperature
+5°C to + 40°C
- Humidity
Max. 95%, non-condensing
- Ingress protection code
IP30
- Product safety
EN60950-1
- Compatibility (EMC)
EN61000-6-1/2, EN61000-6-3/4
Housing dimensions (HxWxD) in mm:
44 x 420 x 225
- Weight
3 kg
- Housing material
Zincor sheet metal, coated front panel
Installation type
Desktop housing stackable, or installation in 19" rack
Complete slide-in module, 1HE (height unit), 84 TE (depth
unit).
Connections
- I/O data cable
Screw terminals for cables up to 0.5 mm
2
- BUS data cable
RJ-45 receptacles or screw terminals for cables up to 0.5
mm
2
- Voltage supply
1.5 m long mains cable with Schuko plug; for low voltage,
screw terminals for cables up to 0.5 mm
2
