The terminal controller is designed for operation in dry rooms at temperatures from +5° C to +40°C.
Mounting
The housing brackets included in the delivery can be used for mounting the controller into 19” modules or screw
fastening to a wall. Without angle brackets, the terminal controller can be placed on a tabletop or even stacked.
Figure 3: Mounting with housing brackets into 19" modules. The rear retaining brackets allow the unit to be pulled
out and hung in the cabinet, e.g. to connect the cables.
