TruVision Series 3 IP Camera FW3.1 Configuration Manual 23
2. Check the check box to enable the UPnP function. You can edit the name of
the device when detected online.
3. Click Save to save changes.
To set up the Email parameters:
1. Click Configuration > Network > Email.
2. Configure the following settings:
Sender: The name of the email sender.
Sender’s Address: The email address of the sender.
SMTP Server: The SMTP server IP address or host name.
SMTP Port: The SMTP port. The default is 25.
Enable SSL: Check the check box to enable SSL if it is required by the
SMTP server.
Attached Snapshot: Check the check box of Attached Snapshot if you
want to send emails with attached alarm snapshots.
Interval: This is the time between two actions of sending attached snapshots.
Authentication: If your email server requires authentication, check this check
box to use authentication to log in to this server. Enter the login user name
and password.
