TruVision Series 3 IP Camera FW3.1 Configuration Manual 39
To set up motion detection in advanced mode:
1. Click Configuration > Basic Event > Motion Detection.
2. Check the Enable Motion Detection box. Check Enable Dynamic Analysis
for Motion if you want to see where has motion real-time.
Note: Select Disable for rules in local configuration menu if you don’t want the
detected objected displayed with the rectangles.
3. Select Advanced mode from the drop down menu.
4. Select OFF, Auto-switch or Scheduled-switch
5. Select Area No. and click Draw Area. Click and drag the mouse on the live
video image to draw an area sensitive to motion detection.
6. Click Stop Drawing to finish drawing. Click Clear All to delete all areas
marked and restart drawing.
7. Move the Sensitivity and Proportion of Object on Area slider to set the
sensitivity and proportion of the detection for different areas
8. Click Edit to edit the arming schedule. See the picture below for the editing
interface of the arming schedule.
9. Choose the day and click to set the detailed time period. You can copy the
schedule to other days.
10. Click OK to save changes.
11. Specify the linkage method when an event occurs. Check one or more
response methods for the system when a motion detection alarm is triggered.
