Interlogix TVW-1120 - IP Wedge Camera Description

12 Installation Guide
Camera description
Figure 1: IP wedge camera
1. Camera cover/housing
2. Lens
3. SD card
4. Ethernet RJ45 PoE port
5. Power supply
6. Base
7. Alarm and Audio port
8. Reset/WPS button
9. Converter pan
10. Antenna
11. Microphone
