Push the black button on the Repeater. The word SUCCESS appears
at the bottom of the Hand-Held’s screen as shown.
Press the <1> function button to select INCLUDE NODE. The screen
refreshes and displays only the line 1 INCLUDE NODE, as shown.
Push the black button on the Repeater. The word SUCCESS appears
at the bottom of the Hand-Held’s screen as shown.
Press the <2> function button on the Hand-Held to select ADD TO
GROUP. The screen refreshes and displays only the line 2 ADD TO
GROUP.
Push the black button on the base of the Panel-Mounted Transceiver.
The screen returns to the full screen with the word SUCCESS at the
bottom, as shown.
Press the <CHLR> button on the Hand-Held Remote to exit
programming mode. When you now carry the Hand-Held Remote in
the problem area, you will now see the words STAT OK on the left
side of the screen.
The repeater is now part of the network. You can add more repeaters as necessary.
REMEMBER: When you have one or more repeaters installed in a network, you increase the
response time: the time between when you press a button on the Hand-Held Remote and when
the reaction takes place.
