Six: Programming the Hand-Held Transmitter 35
Providing a brighter solution.™
Manually Turning Equipment On and Off
At the Control Center
For service purposes, the ve circuits and the pool/spa actuators can be operated manually at the
Control Center.
Simply press any of the circuit buttons on the control pad to toggle between ON and OFF.
Any manual OFF/ON controlling will be reected on the screen of the Hand-Held Controller.
Advanced Features
Configuring Two or More Hand-Held Remote Controllers
Many installations will nd it convenient to use two Hand-Held Remote Controllers. Once you
have linked one Hand-Held to the Control Center, it’s easy to add a additional controllers.
NOTES: The rst Hand-Held you link to the Control Center is considered
the PRIMARY controller and all other units are SECONDARY. You can
tell the status of a controller from the VER (version) code at the top of the
display: the letter “P” = PRIMARY; the letter “S” = SECONDARY.
The PRIMARY controller must be used to “introduce” or link any
additional (SECONDARY) Hand-Held units to the Control Center.
If the PRIMARY controller must be replaced (due to loss, damage, etc.,), you must reprogram
from scratch to create a new PRIMARY controller, then reprogram any additional controllers as
SECONDARY controllers.
Press any button on the Hand-Held Remote to wake it from sleep.
(The unit goes to sleep to conserve battery life when it has been idle
for 60 seconds.) The screen display on the Hand-Held should look
generally like the example on the right.
On both Hand-Held units, press and hold the <P/S> and <CHLR>
buttons at the same time for about 5 seconds to put them into
programming mode, as shown at the right.
On the NEW Hand-Held you are adding to the network:
Press the <5> button to select MORE OPTIONS. A new screen
will appear, as shown at the right.
1.
2.
3.
a.
STAT
OK
POOL
72
ºF SET
P 72
S 85
VER P
STAT
OK
POOL
72
ºF SET
P 72
S 85
VER P
STAT
OK
POOL
72
ºF SET
P 72
S 85
STAT
OK
POOL
72
ºF SET
P 72
S 85
LEA RN VER P
1 INC LUDE NO DE
2 ADD TO GROUP
3 RES ET N ODE
4 RES ET C ONTROLLE R
5 MORE OP TIO NS
C EXI T
LEA RN VER P
1 INC LUDE NO DE
2 ADD TO GROUP
3 RES ET N ODE
4 RES ET C ONTROLLE R
5 MORE OP TIO NS
C EXI T
LEA RN VER x
1 BOOSTER
2 ADD NEW CO NTROL LER
3 ADJ UST TEMP 0
5 PRE VIOU S O PTION S
C EXI T
LEA RN VER x
1 BOOSTER
2 ADD NEW CO NTROL LER
3 ADJ UST TEMP 0
5 PRE VIOU S O PTION S
C EXI T
