44 Mini-Wave PE4 Installation Guide
Copyright © 2006 Intermatic, Inc.
Check that protection for the pool cleaner pump is working (if installed)
What to do If it doesn’t work Reference/Procedure
Make sure all equipment is
OFF but power is present
at the panel.
Make sure the water valves
and actuators are in the
Pool position and the P/S
light on the membrane pad
is OFF.
Push Circuit #1 ON to turn
on the lter pump.
Push Circuit #3 ON to turn
on the cleaner pump.
Push the <P/S> button on
the control to change the
valves over to the SPA.
The cleaner pump should
turn off within ve seconds
of pushing the <P/S>
button.
Wake up the Hand-Held
Remote Transceiver by
pressing any button.
Push button <3> to turn
ON the cleaner pump.
The cleaner pump should
NOT come on because
the valves are in the spa
position.
Push the <P/S> button on
the Hand-Held Remote
Transceiver to change the
valves back to the pool
position.
Push button <3> to turn
on the cleaner pump. The
cleaner pump should now
come ON.
Push the <P/S> button on
the Hand-Held Remote
Transceiver as to change
the valves back to the spa
position.
The cleaner should shut
OFF automatically.
If you can’t complete this
procedure successfully,
follow the steps in the next
column to troubleshoot.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
Verify that the Membrane Pad is
working properly.
Review the What To Do suggestions for the
“Check all circuits using the membrane
pad and wireless remote” troubleshooting
information on page 39.
Verify that the cleaner pump relay is
installed, set up to work with button
<3>, and wired to the cleaner pump.
Review the wiring diagram and instructions on
page 23.
Verify on the Hand-Held remote
Transceiver that BOOSTER protection
has been turned ON.
Review “Programming to Protect a Pool Cleaner
Pump” on page 36.
