Chapter 2 — Spare Parts List
8 EasyCoder PF2i, PF4i, and PF4i Compact Industrial Printers Spare Parts Catalog
Keyboard and Cover, PF2i
Callout Part Number
ROHS Part
Number
Description Remarks
1 1-206461-00 PF2i (IPL) overlay
1 1-206461-20 PF2i (Fingerprint) overlay
2 1-206222-01 Keyboard Excludes overlay
3 1-206453-90 1-206453-90 Door magnet assembly Includes screw
4 1-206113-01 Cover assembly
(Light gray for PF2i and PF4i)
Includes two locking washers
5 1-971633-95 1-971133-900 Console PCB assembly Includes cable and two locking
washers
6 1-206223-90 1-206223-90 Print button assembly
(Dark gray for PF2i and PF4i)
Includes two locking washers
7 1-206468-80 1-206468-80 PF2i (IPL) keyboard assembly Excludes console PCB
7 1-206468-85 1-206468-85 PF2i (Fingerprint)
keyboard assembly
Excludes console PCB
1-206452-50 Badge compact industrial
7
6
5
4
3
2
1
