Intermec EasyCoder PF2i - Media Compartment

Chapter 2 — Spare Parts List
EasyCoder PF2i, PF4i, and PF4i Compact Industrial Printers Spare Parts Catalog 17
Ribbon Supply Unit, PF2i (Option)
Callout Part Number Description Remarks
1 1-975561-04 Ribbon sensor assembly Includes cable
2 1-206146-01 Ribbon supply unit assembly Bobbin, hub with code disc, and spring clutch
3 1-206370-01 Bobbin plate
1
3
2
