Chapter 2 — Spare Parts List
EasyCoder PF2i, PF4i, and PF4i Compact Industrial Printers Spare Parts Catalog 11
Print Mechanism, PF2i
Callout Part Number
ROHS Part
Number
Description Remarks
1 1-010030-90 1-010030-900 Thermal printhead assembly
(8 dots/mm)
Includes bracket and printhead
ribbon break shaft
2 1-2062254-03 1-2069254-03 Guide cover 2” For PF2i
3 1-206273-90 1-206273-90 Cam handle
4 1-206284-01 Edge guide
5 1-206252-02 Paper guide (upper)
6 1-206248-01 Guide link
1-975587-01 Label stop sensor assembly Refer to page 16
7 1-206203-90 1-206203-90 Platen roller/Liner drive roller
8 1-206206-02 Tear bar
1-206114-90 Paper guide assembly Paper guide (upper), LSS
assembly, and guide cover
1
8
7
6
5
4
3
2
