PB3 Mobile Printer User’s Guide 5
3 Insert the end of the battery without contacts into the battery
compartment first. The contact end drops into place.
4 Close the battery door and slide the latch away from the belt loop
knob to lock the latch.
To remove the battery
• Unlock and open the battery door and tip the printer to one side
to remove the battery.
To charge the battery with the AC adapter/charger
1 Plug the AC adapter into the power connector.
2 Install the appropriate AC plug on the adapter. The adapter comes
with four different plugs suitable for most regions worldwide.
3 Make sure the printer is off and connect the adapter to AC power.
The Battery LED turns on, indicating that the battery is charging.
Be sure you insert the battery correctly, or you may damage
the battery contacts in the printer.
Note: If the other LEDs turn on, press the Power button to turn
the printer off.
