26 PB3 Mobile Printer User’s Guide
Accessories
These accessories (sold and ordered separately) are available from
Intermec:
• Battery
• AC Adapter/Charger. Charges the battery and runs the printer on
AC power (battery must be installed or printer will not print).
• Shoulder Strap
• Printhead Cleaning Pen
• Magnetic Stripe Reader (MSR) Cleaning Cards
• Serial Cable
• 3-inch Receipt Paper
• Belt loop
• 2-Bay Battery Charger
• Vehicle Battery Adapter (VBA)/cigarette lighter charger
Pinout Diagram
Serial Port Pin Assignments
Pin Signal Description
1, 5 COM Logic common
2 TXD RS-232 from printer (output)
3 RXD RS-232 from host (input)
4 CTS Clear to send from printer (output)
6 RTS Request to send from host (input)
Pin 1
To Next Page
