PB3 Mobile Printer User’s Guide 25
Specifications
PB3 Mobile Printer Specifications
Specification Description
Height 57 mm (2.25 in)
Width 120 mm (4.75 in)
Length 152 mm (6 in)
Weight (with battery and paper) 0.58 kg (1.3 lb)
Power 7.4 V Li-ion battery, 2200 mAH
Operating temperature -10ºC to 45ºC (14ºF to 113ºF)
Storage temperature -20ºC to 60ºC (-4ºF to 140ºF)
Operating humidity 20% to 85% non-condensing
Storage humidity 5% to 95% non-condensing
Printhead 80 mm (3 in) wide, 203 dpi (8 dots/mm)
Print method Direct thermal
Print speed Up to 5.6 cm/sec (2 in/sec)
Character sets Standard: English/Latin
Optional: Arabic, Simplified Chinese,
Traditional Chinese, Cyrillic, Greek,
Hebrew, Polish
Supported bar codes Codabar, Code 39, UCC/EAN-128,
EAN/UPC, Interleaved 2 of 5, Code 128,
PDF417
Memory 1 MB RAM, 4 MB program flash
Charge time Approximately 180 min
Communications Serial (RS-232), Bluetooth, 802.11g, IrDA
Print ratio 25% black max/sq in
