PB3 Mobile Printer User’s Guide 17
3 Install the battery in the printer and close the battery door. The
printer is now configured for your connection.
DIP Switch Settings
Turn These DIP Switches On
To Set This Parameter 1 2 3 4 5 6 7 8
Enable Bluetooth or 802.11 connection X
Enable RS-232 (serial) connection
Enable IrDA connection with a variable
baud rate of 9600 to 115200
X
Enable IrDA connection with the default
baud rate fixed to 9600
XXX
Set baud rate for IrDA and
RS-232 connections:
115200
57600 X
38400 X
19200 X X
14400 X
9600 X X
2400 X X
1200 X X X
Parity Bit Enabled X
Disabled
(no parity)
Odd/Even (Parity Bit
must be Enabled, and
does not apply to IrDA)
Even X
Odd
Auto Power Save Enabled X
Disabled
Note: If you are configuring the PB3 for a Bluetooth or 802.11
connection, make sure DIP switches 3, 4, and 5 are off.
