LINE CONNECTION
This telephone is supplied with a hybrid plug that suits most common modular RJ style wall sockets, with the
centrepairbeingreservedforspeechandsignaling.Othertypesofplugsandcordsareavailableonrequest.
MESSAGE WAITING LIGHT COMPATIBILITY
All variants of IQ333 offer the following built-in options:
1. 80 VDC type
The Message Waiting switch shown in Fig 1 (when set in the "ON" position) suits an 80 VDC type message
waiting signal from the host system (e.g. NEC, FUJITSU,ALCATEL, later HYBREX and NORTEL).  It
should be set to the OFF position when the telephone is used on other systems
2. Polarity Reversal (e.g. Ericsson BP250)
 Thisfunctionispermanentlyenabledandwillnotconictwithotherfeatureswhenthetelephoneisused
onothersystemswithdifferentMessageWaitingrequirements
3. EricssonMD110(MX-One)orSiemensHi-Path
A software based solution which can be enabled as follows.
Setting Up Software Based Message Waiting
TosetupthetelephoneforEricssonMD110(MX-One)orSiemensHi-PathMessageWaitingsignaldetection,
please use the following keypad entries after connecting the telephone set to the telephone line:
1. Go on-line by lifting the handset or pressing the HANDFREE/HEADSET key, then
 • ToenableEricssonMessageWaiting:
Press STORE, , , 6, 9, 3, STORE,
 • ToenableSiemensMessageWaiting:
Press STORE, , ,6,9,7,STORE,
 • TocanceltheselectedMWoption:
Press STORE, , , 6, 9, 0, STORE,
2. Whenenabled,theMessageWaitingLEDwillblinkforconrmation.
Having enabled Ericsson or Siemens Message Waiting signal detection the large red indicator on the right
hand side above the keypad will indicate when a message is waiting.
NOTE:Ifthistelephoneisconguredto“MessageWaiting”modepleasenotethatitisonlyintendedforPABX
systems(contactyourvendorforclarication).Ifso,itmaynotbeconnectedtoanyothertelephonesystemor
network without the authority of the Australian Telecommunications Authority. For direct line use, please disable
the message waiting feature using the switch on the telephone underside (see Fig 1).
