POOL VACUUM SETUP INSTRUCTIONS
1
2
3
Set up the surface skimmer by following the floating surface skimmer manual.
Turn off filter pump.
Remove the basket
(9)
, cover rim
(7)
and the floating cover
(6)
from the
skimmer.
6
7
9
Place the debris bag
(4)
in the vacuum body
(5)
. Press and hold the
clip on the vacuum body and close the vacuum cover
(3)
by turning
clockwise.
PRESS
4
Place the vacuum assembly into the skimmer, turn clockwise to connect.
3
4
5
2
1
3
4
5
3
3
5
