Invacare Bed Rails - Detailed Parts List for 6623

Standard Telescope Bed Rails
6623
This Model was discontinued 1/8/03
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1135777 Kit, Telescoping Bed Rail 1 21 A
Washer, Nylon (3/16 x 7/16 x 1/8") 1 22
Rivet (3/16 x 7/16") 1 23
Pin, Plunger 1 24
Spring, Plunger (23/64 x 5/8") 1 25
Plug Button, Grey (7/8") 1 26
Knob, Plunger, Grey 1 27
Rail, Telescoping - Outside 1 18
Rail, Telescoping - Inside 1 19
Label, Entrapment Warning 1 1
1021834 Kit, Crossbrace Assembly 1 210 B
Barrel, Right 1 111
Barrel, Left 1 111
Washer, Flat (5/16 x 11/16 x 1/16") 1 212
Locknut (5/16-18) 1 213
Nut, Wing (1/4-20) 1 215
Clamp Bar 1 216
Bolt, Carriage (1/4-20 x 1-1/4") 1 217
Channel Only, Granite 1 118
1028789 Kit, Frame Bar (Pair) 1 114 C
Bolt, Carriage (1/4-20 x 1-1/4") 1 215
Clamp Bar 1 216
Nut, Wing (1/4-20) 1 217
1012658-NLA NLA - Spacer, Tube 1 2D,E
A - Includes: Items 2-9 and the Warning Label
B - Includes: Items 11-18
C - Includes: Items 15-17
D - Before 8/11/97 only.
E - Not Shown
2/1/04
the rails will have 4 rungs instead of 3 so an inner and an outer Rail needs to be ordered when replacing.
NOTE:
10
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 92-048
