31
SECTION 7—OPTIONS
S E C T I O N 7 — O P T I O N S
Installing/Adjusting Headrest
W A R N I N G
After ANY adjustments, repair or service and before use, make sure all attaching
hardware is tightened securely - otherwise injury or damage may occur. To adjust
the headrest, refer to dedicated paragraph in user manual.
Installing/Adjusting Headrest
NOTE: For this procedure, refer to FIGURE 7.1.
1. Install the back brace. Refer to Installing removing the back-brace paragraph.
2. Set the Headrest bracket (mounting bolts, headrest bracket and the hand wheel
A
)
in the fixing holes on the back-brace tube.
3. Introduce the vertical tube
B
that support the headrest cushion into the headrest
bracket.
4. Adjust to the appropriate height position with the user sat into the chair, tighten the
hand wheel
A
.
5. Adjust the headrest cushion (depth and angle position) and tighten securely the
screws
C
and the handle
D
.
FIGURE 7.1
Installing/Adjusting Headrest
