Invacare G32 - Setup Procedures; Qualified Technicians for Setup; Label Locations and Identification; Component Identification

G5510BedArticulatingHeadRails
Setup
QualiedTechniciansOnly
WARNING!
RiskofInjuryorDamage
Set-upbyunqualiedtechniciansmayresultin
injuryordamage
–TheproceduresinthisSetUpsectionMUSTbe
performedbyaqualiedtechnician.
LabelLocations
ITEMPART
NUMBER
DESCRIPTION
AccessoriesSecuredLabel
V
1180202
PinchPointWarningLabel
W
1079203
FootCrushWarningLabel
X
1180194
PatientEntrapmentWarning
Label
Y
1180201
BedRailEntrapmentDangerLabel
Z
60101880
Labelsmaychangewithoutnotice.ContactInvacare
iflabelsaremissingorunreadable.
ComponentIdentication
RightSideandLeftSideIdentication
RightSideandLeftSideofthebedaredetermined
bysitting/layinginthebed.
Therearetwobedrails:HeadRailRightSideand
HeadRailLeftSide.Eachrailisuniqueandbuiltto
mountonlyinit’sdesignatedlocation(Example:The
HeadRailRightSidewillonlymountontherightside
oftheheadsection.Itwillnotmountontheleft
sideoftheheadsection.Theheadrailrightsideis
identiedby“HR”embossedonattachingbracket.
BedRailandAttachingHardware
1.Foreaseofinstallation,separatetheindividual
components:
KnobAAttachingBracketC
SpacerBBedRailD
EnsuretousecorrectattachingbracketCwithrailD.
AttachingBracketBedRail
HR
HeadSectionRight
HL
HeadSectionLeft
4
60105588-A
