G5510BedArticulatingHeadRails
Foreasierinstallation,theendofthethreaded
rodonthe“T”bracketKshouldbeinsidethe
outeredgeNofthebedframe.
SIDEVIEWOFBEDRAILINSTALLEDONBEDFRAME
2.WhilehookingthebedrailclampJontothebedframe
L,slidetheattachingbrackettowardthebedrailand
slidethe“T”bracketKoftheattachingbracketC
throughthebedrailclampJ.
3.Slidethebedrailassembly(bedrailandattaching
bracket)towardthefootboardengagingthetwo“L”
bracketsEoftheattachingbracketCunderneaththe
secondGandthirdHcrossmembers.
4.InstallspacerBandknobAontotheattachingbracket.
5.Securelytightentheknob.
6.Repeatsteps1–5toinstallHeadEndLeftSideRailonto
theleftsideoftheheadsection.
BedRailInstalled
HEADEND
FOOTEND
660105588-A
