SECTION 5—OPERATING INSTRUCTIONS
Part No 1143482 17 Perfecto
2
™
Series
FIGURE 5.2 Humidifer Bottle Adapter
5. Attachthehumidifierbottleadaptertothehumidifier
bottlebyturningthewingnutonthehumidifierbottle
counterclockwiseuntilitissecurelyfastened.SeeDetail
“A ” inFIGURE5.3.
6. Placethehumidifierbottle/adapterassemblyinthe
humidifiercompartmentontheconcentrator.SeeDetail
“B”inFIGURE5.3.
7. Attachoxygentubingfromthehumidifierbottle/adapter
assemblytooxygenoutletconnectorontheconcentrator.
SeeDetail“B”inFIGURE5.3.
8. Attachthecannula/patient supplytubingtothe
humidifierbottleoutlet.SeeDetail“B”inFIGURE5.3.
9. Afterassembly,ensurethatoxygenisflowingthroughthe
cannula.
Filter Access Door
Cabinet Filter
Humidifier
Bottle Adapter
Insert Flat Head
Screwdriver
Here
