SECTION 5—OPERATING INSTRUCTIONS
Perfecto
2
™
Series 16 Part No 1143482
Set Up
Plug in Power Cord
Pluginpowercordtoanelectricaloutlet.
Connect Humidifier (If So Prescribed)
 WARNING
DONOToverfillhumidifier.
DONOTreversetheoxygeninputandoutputconnections.
Waterfromthehumidifierbottlewilltravelthroughthe
cannulabacktothepatient.
NOTE:Forthisprocedure,refertoFIGURE5.1,FIGURE5.2on
page 17,FIGURE5.3onpage 18.
1. Removecapfrombottle.
2. Fillhumidifierwithdistilledwatertothelevelindicated
bythemanufacturer.Replacethehumidifiercapand
securelytighten.
FIGURE 5.1 Filling the Humidifier
3. Insertaflatheadscrewdriverintheplategrooveonthetop
edgeofthefilteraccessdoorandgentlyprythefilter
accessdooroff(FIGURE5.2).
4. Pullupandremovethehumidifierbottleadapter
(FIGURE5.2).
Humidifier
Bottle w/o Cap
Humidifier
Bottle with Cap
