SECTION 5—OPERATING INSTRUCTIONS
Perfecto
2
Series 18 Part No 1143482
FIGURE 5.3 Humidifier Compartment
Power Switch
NOTE:Forthisprocedure,referto
FIGURE5.4.
1. Presspowerswitchtoon
position.Allthepanel
lightsandtheaudible
alarmwillcomeonfor
onesecond,indicating
thattheunitisfunctioning
properly.
FIGURE 5.4 Power Switch
Humidifier
Bottle
Humidifier
Compartment
Humidifier
Bottle
Adapter
Humidifier
Bottle
DETAIL “A”
DETAIL “B”
Oxygen
Tubing
Oxygen Outlet
Connector
Humidifier
Bottle
Outlet
On/Off
(I/O)
Power
Switch
