SECTION 5—OPERATING INSTRUCTIONS
Perfecto
2
™
Series 20 Part No 1143482
FIGURE 5.5 Flowrate
Front Panel Indicators - Units with
SensO
2
TheSensO
2
featuremonitorsthepurityofoxygengenerated
bytheoxygenconcentrator.Ifpurityfallsbelowfactorypreset
standards,indicatorlightsonthecontrolpanelwill
illuminate.
FIGURE 5.6 Front Panel Indicators - Units with SensO2
Flow Knob
Ball
Flowmeter
Front Panel
0.5 L/min
O
2
Auto Shut Down
Use Backup
Below
Normal
Normal
RED
Call Supplier
YELLOW
GREEN
OXYGEN PURITY
