Tilt/Recline Seating Systems® 26 Part No. 1114822
FIGURE 1 - USING OPTIONAL VERNIER SHEAR REDUCTION
INDEPENDENTLY OF RECLINE FUNCTION
Four-Way Toggle
Switch (Shown in
Neutral Position)
NOTE: If the wheelchair is equipped with switch options, scan to the correct ECU or Auxiliary
Mode and activate the control device in the corresponding left direction to operate the VSR
function. Refer to the MK5 owner's manual, part number 1114808 for complete switch option
operating instructions.
4. Return the back to the position noted in STEP 2 BEFORE changing the degree of
recline.
SHEAR REDUCTIONSECTION 7
SHEAR REDUCTION
