Invacare Perfecto2 IRC5PO2 User Manual

SECTION 5—OPERATING INSTRUCTIONS
Part No 1143482 15 Perfecto
2
™
Series
Set Up
Plug in Power Cord
Plug in power cord to an electrical outlet.
Connect Humidifier (If So Prescribed)
 WARNING
DO NOT overfill humidifier.
DO NOT reverse the oxygen input and output connections.
Water from the humidifier bottle will travel through the
cannula back to the patient.
NOTE: For this procedure, refer to FIGURE 5.1, FIGURE 5.2 on
page 16, FIGURE 5.3 on page 17.
1. Remove cap from bottle.
2. Fill humidifier with distilled water to the level indicated
by the manufacturer. Replace the humidifier cap and
securely tighten.
FIGURE 5.1 Filling the Humidifier
3. Insert a flathead screwdriver in the plate groove on the top
edge of the filter access door and gently pry the filter
access door off (FIGURE 5.2).
4. Pull up and remove the humidifier bottle adapter
(FIGURE 5.2).
Humidifier
Bottle w/o Cap
Humidifier
Bottle with Cap

Invacare Perfecto2 IRC5PO2 Specifications

General

Flow Rate	0.5 to 5 LPM
Outlet Pressure	5.5 PSI
Oxygen Concentration	87% to 95.6%
Dimensions	23 in (H) x 13 in (W) x 12 in (D)
Electrical Requirements	120 VAC, 60 Hz
Operating Temperature	55°F to 90°F (12°C to 32°C)
Operating Humidity	up to 95% non-condensing
Sound Level	≤45 dB(A)
Noise Level	≤45 dB(A)
