Invacare Perfecto2 IRC5PO2 User Manual

SECTION 5—OPERATING INSTRUCTIONS
Part No 1143482 21 Perfecto
2
™
Series
Initial Startup of the Concentrator
NOTE: Concentrator may be used during the initial start warm-up
time (approximately 30 min). O
2
purity will build to a maximum
during this period.
LABEL
SYMBOL
STATUS INDICATOR LIGHTS
(LED)
SYSTEM OKAY GREEN Indicator Light
SYSTEM FAILURE RED Indicator light
Continuous Audible Alarm
Sieve-GARD™Compressor
Shutdown
Call a qualified technician. Switch
to a back-up supply of oxygen
immediately.
I/O

Invacare Perfecto2 IRC5PO2 Specifications

General

Flow Rate	0.5 to 5 LPM
Outlet Pressure	5.5 PSI
Oxygen Concentration	87% to 95.6%
Dimensions	23 in (H) x 13 in (W) x 12 in (D)
Electrical Requirements	120 VAC, 60 Hz
Operating Temperature	55°F to 90°F (12°C to 32°C)
Operating Humidity	up to 95% non-condensing
Sound Level	≤45 dB(A)
Noise Level	≤45 dB(A)
