Above data is subject to change without notice.
NO.
Description
Part Code
Qty
L4VO32-09
1 Electric Box Assy 100002002657 1
2 Electric Box 20113034 1
3 Main Board 300027000249 1
4 Reactor 43130184 1
5 Terminal Board 42010313 1
6 Wire Clamp 71010103 2
7 Front Grill 22413049 1
8 Front Panel 01533034P 1
9 Axial Flow Fan 10333004 1
10 Chassis Sub-assy 017000000134P 1
11 Brushless DC Motor 1501308507 1
12 Top Cover Sub-Assy 01253073 1
13 Motor Support 01703104 1
14 Condenser Assy 011002000372 1
15 Rear Grill 01473009 1
16 Capillary Sub-assy 030006000337 1
17 Cut off Valve 071302391 1
18 Big Handle 2623343106 1
19 Cut off Valve 071302391 1
20 Valve Support 01713142P 1
21 Right Side Plate Sub-Assy 01303178 1
22 4-Way Valve Assy 030152000171 1
23 Clapboard Sub-Assy 0123338502 1
24 Magnet Coil 4300040050 1
25 Compressor and Fittings 00103925G 1
26 Electrical Heater / /
27 Electrical Heater (Chassis) / /
28 Drainage Connecter 06123401 1
To Next Page
