Above data is subject to change without notice.
NO.
Description
Part Code
Qty
L4VO32-12
1 Left Side Plate 01303200P 1
2 Fan Motor 1501308507 1
3 Motor Support 01703136 1
4 Condenser Assy 011002000359 1
5 Top Cover Sub-Assy 01253081 1
6 Rear Grill 01475014 1
7 Clapboard Sub-Assy 01233180 1
8 Compressor and Fittings 00103925G 1
9 Compressor Gasket 76710287 3
10 4-Way Valve Assy 030152000016 1
11 Big Handle 2623343106 1
12 Valve Cover 22243006 1
13 Cut off Valve 071302391 1
14 Cut off Valve 07130239 1
15 Valve Support 0171314201P 1
16 Front Grill 22413044 1
17 Cabinet 01433033P 1
18 Axial Flow Fan 10333011 1
19 Chassis Sub-assy 017000000091P 1
20 Electric Box Assy 100002001110 1
21 Electric Box 20113032 1
22 Main Board 300027000261 1
23 Reactor 43130184 1
24 Wire Clamp 71010103 2
25 Terminal Board 42010313 1
26 Electrical Heater / 1
27 Electrical Heater (Chassis) / 1
To Next Page
