12 | Optidrive CoolVert User Guide | Version 1.00 www.invertekdrives.com
3
Installation
Supply Rating
Output
Rating
Product Part
Number
Switching
frequency
Typical
Output
Power
Approximate
drive
efficiency
Approximate
losses at
typical
power
Maximum
coldplate
or Heatsink
temperature
V Ph A kW Model kHz kW % W ◦C
200-240V
+/-10%
1 7 1.5
CV-220070-3FCP
CV-220070-3FHP
4 1.5 95.0% 75.45 95
8 1.5 94.3% 85.5 92
12 1.5 93.7% 95.1 89
16 1.5 93.2% 102.45 86
24 1.5 91.9% 121. 9 5 83
32 1.5 90.2% 14 7. 75 80
200-240V
+/-10%
1 12 2.2
CV-220120-3FCP
CV-220120-3FHP
4 3 94.5% 165.3 95
8 3 94.0% 179. 4 92
12 3 94.0% 180.9 89
16 3 93.3% 201.6 86
24 3 92.3% 230.7 83
32 3 92.3% 231. 3 80
380-480V
+/-10%
3 14 5.5
CV-240140-3FCE
CV-240140-3FHE
10 5.5 96.7% 18 4 91
12 5.5 96.4% 19 8 89
14 5.5 96.2% 211 88
16 5.5 96.1% 217 87
18 5.5 95.7% 235 85
20 5.5 95.5% 246 84
380-480V
+/-10%
3 18 7. 5
CV-240180-3FCE
CV-240180-3FHE
10 7. 5 94.9% 380 91
12 7. 5 94.5% 410 89
14 7. 5 94.1% 440 88
16 7. 5 96.3% 2 81 87
18 7. 5 93.2% 509 85
20 7. 5 95.8% 315 84
380-480V
+/-10%
3 24 11
CV-240240-3FCE
CV-240240-3FHE
10 11 96.8% 358 91
12 11 96.7% 359 89
14 11 96.7% 363 88
16 11 96.6% 370 87
18 11 96.5% 383 85
20 11 96.4% 393 84
