Invertek OPTIDRIVE Coolvert - Product Introduction; Drive Model Identification

Version 1.00 | Optidrive CoolVert User Guide | 5www.invertekdrives.com
2
Product Introduction
2
Product Introduction
2. Product Introduction
The Optidrive Coolvert is a high efficiency variable frequency drive with world-leading motor control performance when operating
any of the following motor technologies:
Induction Motor
Synchronous Permanent Magnet Motor
Synchronous Brushless DC Motor
Synchronous Reluctance Motor
Line Start Permanent Magnet Motor
The product range has been specifically designed for OEM and machine-builders alike with through panel mounting and cold-plate
technology options available. The drive has no direct keypad/display but shows drive status with two status indicating LEDs on the
front.
The three phase input drives are low harmonic drives which do not need an input choke to comply with the THC limits provided in the
relevant standard, BSEN 61000-3-12:2011. The single-phase input drives have built-in active PFC (Power Factor Correction) and in
turn, are compliant with the requirements of BSEN 61000-3-2.
2.1. Identifying the Drive by Model Number
Each drive can be identified by its model number, shown below. The model number is on the shipping label, the drive rating label
on the upper surface of the drive and on the front surface on the product identifier. The model number includes the drive and factory
fitted options.
CV - 2 2 0070 - 1 F H P
Product Family
CV: CoolVert
E : Eco Film Capacitor
P : Active PFC
Frame Size
H : Heatsink
C : Coolpate
Voltage Rating
2 : 200V
4 : 400V
F : Internal EMC Filter
Current Rating x 10
0070 = 7.0A
Number of Input Phases
2.1.1. Model Variants
200 – 240V +/-10% Single Phase Input
Model Code Frame kW HP Amps
CV-220070-1FHP 2 1.5 2 7. 0
CV-220120-1FHP 2 3 3 12.0
380 – 480V +/-10% Three Phase Input
Model Code Frame kW HP Amps
CV-240140-3FHE 2 5.5 7. 5 14
CV-240180-3FHE 2 7. 5 10 18
CV-240240-3FHE 2 11 15 24
Replace ‘H’ with ‘C’ for coldplate version.
