44 | Optidrive CoolVert User Guide | Version 1.00 www.invertekdrives.com
6
Technical Data
Conformance
The CoolVert product range conforms to the relevant safety provisions of the following council directives: 2014/30/EU (EMC) and
2014/35/EU (LVD).
Designed and manufacture is in accordance with the following harmonised European standards:
EN 61800-5-1: 2007 & A1: 2017 Adjustable speed electrical power drive systems. Safety requirements. Electrical, thermal
and energy.
EN 61800-3: 2004 & A1 2012 Adjustable speed electrical power drive systems. EMC requirements and specific test
methods.
EN 55011: 20016 & A1: 2017 Limits and Methods of measurement of radio disturbance characteristics of industrial,
scientific and medical (ISM) radiofrequency equipment (EMC).
EN60529: 1992 & A2: 2013 Specifications for degrees of protection provided by enclosures.
UL 61800-5-1 cUL Listed *
RohS
* Pending. Drive variants with a heatsink are cUL listed whereas the coldplate variants are cUR recognised.
6.2. Detailed Product Rating Tables
Part Number Power
Rating
Input
Current
Fuse or MCB
(Type B)
Max Input
Cable Size
Continuous
Output
Current
Overload
Output
Current
Maximum
Output
Cable Size
Maximum
Motor Cable
Length
kW HP A Non UL UL mm
2
awg A A mm
2
awg m ft
CV-240070-1FHP 1.5 2 8.9 16 15 16 6 7 9.1 6 10 10 33
CV-240120-1FHP 3 3 15 . 8 25 25 16 6 12 13 . 2 6 10 10 33
CV-240070-1FCP 1.5 2 8.9 16 15 16 6 7 9.1 6 10 10 33
CV-240120-1FCP 3 3 15. 8 25 25 16 6 12 13 . 2 6 10 10 33
CV-240140-3FHE 5.5 7. 5 12 16 15 6 10 14 18.2 6 10 10 33
CV-240180-3FHE 7. 5 10 16 25 25 6 10 18 23.4 6 10 10 33
CV-240240-3FHE 11 15 22 25 25 6 10 24 28 6 10 10 33
CV-240140-3FCE 5.5 7. 5 12 16 15 6 10 14 18.2 6 10 10 33
CV-240180-3FCE 7. 5 10 16 25 25 6 10 18 23.4 6 10 10 33
CV-240240-3FCE 11 15 22 25 25 6 10 24 28 6 10 10 33
NOTE Maximum permissible motor cable without the use of output filters is 10m with shielded cable and 20m with unshielded cable
– for all ratings.
6.3. Temperature and Switching Frequency De-rating Requirements for Coolvert
6.3.1 230V Single Phase
CV-220070-1FHP / CV-220070-1FCP
Switching
Frequency
Maximum continuous output current at ambient temperature
0 10 20 30 40 50 60
4 kHz 7 7 7 7 7 7 7
8 kHz 7 7 7 7 7 7 7
12 kHz 7 7 7 7 7 7 7
16 kHz 7 7 7 7 7 7 7
24 kHz 7 7 7 7 7 7 4.7
32 kHz 7 7 7 7 7 6.5 3.7
