Technical Data
6. Technical Data
6.1. General
Input Ratings
Supply Voltage 200 - 240V ± 10%
380 - 480V ± 10%
Maximum Isc 100kA when installed in a suitable enclosure
Supply Frequency 48 - 62Hz
Displacement Power Factor >0.98
Permissible phase imbalance 3% maximum
Inrush Current < rated current
Power Cycles 120 per hour evenly spaced
Output Ratings
Output Power 200V: 1.5 - 3.0kW
400V: 5.5 - 11kW
Overload Capacity 130% for 10s - see rating tables for detailed values
Output Frequency 0-500Hz
Acceleration Time 0.01 - 600s
Deceleration Time 0.01 - 600s
Maximum Motor Cable Length 10m shielded, 20m unshielded
Ambient Conditions
Temperature Storage: -40°C to 70°C
Operation: -20°C to 60°C
Altitude Up to 1000m ASL without derating
Up to 2000m ASL UL approved
Up to 4000m ASL maximum (non UL)
Humidity 95% Maximum, non-condensing
Vibration Conforms to EN61800-5-1
Environmental
Ingress Protection (IP) Front IP20
Rear (Through Panel Mounting) IP55
Coated PCBs Designed for operation in 3S2/3C2 environments according to IEC 60721-3-3
Programming
Modbus RTU (RS485) Modbus RTU on Pluggable terminals and through RJ45 port
PC Tools PC Tools software for Diagnostics and parameter configuration (RJ45 port only)
Keypad Optional Remote Keypad with TFT display for diagnostic and programming
