28 | Optidrive CoolVert User Guide | Version 1.00 www.invertekdrives.com
4
Set-up and Operation
4.3. Read-only Parameter List and Modbus Registers
Register Comment Command Type Scaling Parameter
1 Drive Control Command Word 03, 06, 10 Read/Write -
2 Speed Set Point (RPS) 03, 06, 10 Read/Write 600 = 60.0 rps -
4 Modbus User Ramp Time 03, 06, 10 Read/Write 3000 = 300.0 Seconds -
5 Speed Reference (IDL format) 03, 06, 10 Read/Write 3000 = 50.0Hz -
6 Drive Status 3 Read Only -
7 Output Frequency (Motor Speed) 3 Read Only 600 = 60.0 rps P00-60
8 Output Current 3 Read Only 100 = 10.0 Amps -
9 Trip Code 3 Read Only -
10 Output Power 3 Read Only 1000 = 10.00kW -
11 Digital Input Status 3 Read Only Bit 0 = Digital input 1, etc P00-03
12 Rating ID 3 Read Only P00-29
13 Power Rating 3 Read Only P00-29
14 Voltage Rating 3 Read Only P00-29
15 IO Processor Software Version 3 Read Only 100 = 1.00 P00-28
16 Motor Control Processor Software Version 3 Read Only 100 = 1.00 P00-28
17 Drive Type 3 Read Only P00-29
20 Analog Input Signal Level 3 Read Only 1000 = 100.0% P00-01
22 Pre Ramp Speed Reference (RPS) 3 Read Only 600 = 60.0 rps P00-04
23 DC bus Voltage 3 Read Only 600 = 600 Volts P00-20
24 Drive Temperature 3 Read Only 40 = 40°C P00-21
25 Drive Serial Number 4 3 Read Only P00-30
26 Drive Serial Number 3 3 Read Only P00-30
27 Drive Serial Number 2 3 Read Only P00-30
28 Drive Serial Number 1 3 Read Only P00-30
29 Relay Output Status 3 Read Only 0 = Open, 1= Closed -
32 kWh Meter 3 Read Only 100 = 10.0kWh P00-26
33 MWh Meter 3 Read Only 100 = 100MWh P00-27
34 Running Time – hour 3 Read Only P00-31
35 Running Time – min/sec 3 Read Only P00-31
36 Running Time since last enable – hour 3 Read Only P00-34
37 Running Time since last enable – min/sec 3 Read Only P00-34
39 Room (Control PCB) Temperature 3 Read Only 40 = 40°C P00-05
40 Speed Reference value 3 Read Only 3000 = 50Hz
42 Motor Speed (IDL Format) 3 Read Only 3000 = 50Hz
43 Motor output voltage 3 Read Only 100 = 100V (AC) P00-11
44 Indirect Parameter Access Index 3 Read/Write -
45 Indirect Parameter Access Value 3 Read/Write -
