Version 1.00 | Optidrive CoolVert User Guide | 45www.invertekdrives.com
6
Technical Data
CV-220120-1FHP / CV-220120-1FCP
Switching
Frequency
Maximum continuous output current at ambient temperature
0 10 20 30 40 50 60
4 kHz 12 12 12 12 12 12 11 . 5
8 kHz 12 12 12 12 12 12 10
12 kHz 12 12 12 12 12 11 . 5 9
16 kHz 12 12 12 12 12 11 8.5
24 kHz 12 12 12 12 12 10.5 8
32 kHz 12 12 12 12 12 9.5 7. 5
6.3.2 400V 3-phase Models
CV-240140-3FHE / CV-240140-3FCE
Switching
Frequency
Maximum continuous output current at ambient temperature
0 10 20 30 40 50 60
10 kHz 14 14 14 14 14 14 14
12 kHz 14 14 14 14 14 14 14
14 kHz 14 14 14 14 14 14 13 . 5
16 kHz 14 14 14 14 14 14 13
18 kHz 14 14 14 14 14 14 12.5
20 kHz 14 14 14 14 14 14 11 . 5
CV-240180-3FHE / CV-240180-3FCE
Switching
Frequency
Maximum continuous output current at ambient temperature
0 10 20 30 40 50 60
10 kHz 18 18 18 18 18 18 18
12 kHz 18 18 18 18 18 18 16.5
14 kHz 18 18 18 18 18 18 15
16 kHz 18 18 18 18 18 18 13. 5
18 kHz 18 18 18 18 18 17 12
20 kHz 18 18 18 18 18 16 10
CV-240240-3FHE / CV-240240-3FCE
Switching
Frequency
Maximum continuous output current at ambient temperature
0 10 20 30 40 50 60
10 kHz 24 24 24 24 24 24 22
12 kHz 24 24 24 24 24 23 18
14 kHz 24 24 24 24 24 21 16.5
16 kHz 24 24 24 24 24 19 15
18 kHz 24 24 24 24 24 17. 5 14
20 kHz 24 24 24 24 24 17 13
 The drive is protected against short-circuit from power output to protective earth for all rated cable lengths, cable sizes and cable types.
 The maximum cable lengths stated here are based on hardware limitations and do NOT take into consideration any requirements
for compliance to any EMC standards. Please see section 3.3. EMC Compliant Installation on page 14 for further information.
 Supply and motor cable sizes should be dimensioned according to local codes or regulations in the country or area of installation.
 For UL compliant installation, use Copper wire with a minimum insulation temperature rating of 70°C, UL Class CC or Class J
Fuses.
