30 | Optidrive CoolVert User Guide | Version 1.00 www.invertekdrives.com
4
Set-up and Operation
Par Description Display Range Note
Comms
Register
P0-34 Run time since enable Display in hours and
minutes since enable
Two entries over Modbus - First is Hour
Second is minute and second
36
37
P0-35 Drive cooling fan run time Display in hours -
P0-36 DC bus voltage log (256ms) Most recent 8 samples
prior to trip
Eight entries -
P0-37 DC bus voltage ripple log (20ms) Most recent 8 samples
prior to trip
Eight entries -
P0-38 Heatsink temperature log (30s) Most recent 8 samples
prior to trip
Eight entries -
P0-39 Ambient temperature log (30s) Most recent 8 samples
prior to trip
Eight entries -
P0-40 Motor current log (256ms) Most recent 8 samples
prior to trip
Eight entries -
P0-41 Critical fault counter – O-I O-I trip counter
(including h O-I)
No decimal place -
P0-42 Critical fault counter – O-Volts Over volts trip counter No decimal place -
P0-43 Critical fault counter – U-Volts Under volts trip counter No decimal place -
P0-44 Critical fault counter – O-Temp
(H/sink)
IGBT over temperature
trip counter
No decimal place -
P0-46 Critical fault counter –
O-Temp(Amb)
Trip level is 85 degree
C
No decimal place -
P0-47 Internal I/O comms error count 0 … 65535 No decimal place -
P0-48 Internal DSP comms error count 0 … 65535 No decimal place -
P0-49 Modbus comms error count 0 … 65535 No decimal place -
P0-53 Current Phase U offset and ref Internal value -
P0-54 Current Phase V offset and ref Internal value -
P0-55 Current Phase W offset and ref Internal value -
P0-56 Drive life time Hour/min/sec -
P0-57 Ud/Uq Internal value No decimal place -
P0-58 Output Current A -
P0-59 Output Power kW -
P0-60 Output Frequency rps 600 = 60.0rps with one decimal place -
P0-61 Post ramp speed reference rps 600 = 60.0rps with one decimal place -
P0-62 User ramp value S2…S3 0.00 to 600s; S2…S3 1 = 0.01s with 1dp display as 0.01s~0.09s, 0.1s
~9.9s, 10s~600s
-
P0-63 Overload level % % of overload level -
P0-64 Switching frequency internal 4 ~ 32kHz -
P0-65 Motor control lib version 1 motor control lib version -
