involight TRINITY200LED - Page 29

28
Fixture
Channel Mode
Standard
Mode
This allows you to select your desired DMX channel
mode.
a) Press the (Enter) key until “Channel Mode” is
displayed.
b) To select the desired DMX mode, press the ▲ (Up)
or ▼ (Down) button.
c) To confirm and exit the menu, press the (OK) key
d) Press the (Return) key to exit the selection without
saving.
Extend
Mode
Pan/Tilt Setting
Invert Pan
Pan-tilt inversion.
a) Press the (Enter) key until "Pan Invert" or "Tilt Invert"
is displayed.
b) Press the ▲ (Up) or ▼ (Down) button until "Yes" or
"No" is displayed.
c) To confirm and exit the menu, press the (OK) key
d) Press the (Return) key to exit the selection without
saving.
Invert Tilt
Swap Pan-
Tilt
The PAN and Tilt channels can be swapped under
PAN / TILT SWAP.
a) Press the (Enter) key until "Swap Pan-Tilt" is
displayed.
b) Press the ▲ (Up) or ▼ (Down) button until "On" or
"Off" is displayed.
c) To confirm and exit the menu, press the (OK) key
d) Press the (Return) key to exit the selection without
saving.
W-DMX
Activate W-DMX mode.
a) Press the (Enter) key until “W-DMX” is displayed.
b) Press the ▲ (Up) or ▼ (Down) button until "On" or
"Off" is displayed.
c) To confirm and exit the menu, press the (OK) key
d) Press the (Return) key to exit the selection without
saving.
Manual
Reset
Head Reset
With this function you can reset the device.
a) Press the (Enter) key until "Reset" is displayed.
b) To select the desired reset functions, press the ▲
(Up) or ▼ (Down) button.
c) To confirm and exit the menu, press the (OK) key
d) Press the (Return) key to exit the selection without
saving.
Pan/Tilt
Reset
All reset
