BPD series PV pumping inverter Product overview
10
⑤
⑦
⑥
①
②
③
②
③
④
(b) BPD004TNAC terminals
①
⑧
②
③
⑥
②
③
⑤
⑦
④
⑨
(c) BPD2K2–5K5TRAC(S) terminals
Figure 2.2 Wiring terminal arrangement
No.
Terminal name
Pin definition
①
AC input
terminal (AC
model)
-TN model
1. L
2. N
3. PE
-TR model
1. R
2. S
3. T
