BPD series PV pumping inverter Product overview
14
2.6 Dimensions and installation
W1
H1
D
W2
H2
Figure 2.5 Dimensions of BPD0K7TN(AC)
(Unit: mm)
Model
H1
W1
D
H2
W2
Installation
hole
BPD0K7TN(AC)
255
300
137
118.5
195
8
W1
H1
D
W2
H2
Figure 2.6 Dimensions of BPD1K5/2K2TN(AC)
