INVT BPD2K2TNAC User Manual

BPD series PV pumping inverter Function parameters
45
Function
code
Name
Detailed description
Default
Modify
For models of 220V, the default value is 330.0V,
and for models of 380V, the default value is
570.0V.
Setting range: 220.0V–600.0V
model
P18.07
PV input power
Reserved. Unit: W
●
P18.10
Device
configuration
display
0: PV power supply
1: AC grid power supply
●
P18.11
Current flow of
pump
*/Q Q f f
NN

, unit: m
3
/h
0.0
●
P18.12
Current lift of
pump
2
0.9 * ( / )H H f f
NN

, unit: m
0.0
●
P18.13
MSB of pump
total flow
Displaying the most significant 16 bits of the total
flow of the pump. Unit: m
3
0
●
P18.14
LSB of pump
total flow
Displaying the least significant 16 bits of the total
flow of the pump. Unit: m
3
Total flow of pump = P18.13 x 65535 + P18.14
0.0
●
P18.15
Pump total
flow reset
When P18.15 is set to 1, the total flow of the pump
is reset, and P18.13 and P18.14 are reset to zero
to re-calculate the flow. After the reset, P18.15 is
automatically modified to 0.
0
◎
P19 Group Voltage boost
P19.06
Bus voltage
reference
It is used to set the reference voltage of the bus
when PV input is adopted.
For models of 220V, the default value is 330.0V,
and for models of 380V, the default value is
570.0V.
Setting range: 220.0V–600.0V
Depend
on
model
◎
