INVT BPD2K2TNAC User Manual

BPD series PV pumping inverter Appendix: Recommended solar array configuration
70
Appendix: Recommended solar array configuration
Inverter model
Open-circuit voltage degree of solar module
37±1V
45±1V
Module power
(±5 Wp)
Modules per
string x strings
Module power
(±5 Wp)
Modules per
string x strings
BPD0K7TN(AC)
250
5 x 1
300
4 x 1
BPD1K5TN(AC)
250
8 x 1
300
7 x 1
BPD2K2TN(AC)
250
10 x 1
300
8 x 1
BPD004TNAC
250
10 x 2
300
8 x 2
BPD2K2TRAC(S)
250
10 × 1
300
8 x 1
BPD004TRAC(S)
250
10 × 2
300
8 x 2
BPD5K5TRAC(S)
250
14 × 2
300
12 x 2
