BPD series PV pumping inverter Function parameters
32
Function
code
Name
Detailed description
Default
Modify
44: Switch between solar input and power
frequency input
45: Full-water signal
46: Non-water signal
47–63: Reserved
P05.10
Polarity
selection of the
input terminals
If the bit is 0, the input terminal is positive;
If the bit is 1, the input terminal is negative.
BIT4
BIT3
BIT2
S4
S3
S2
The setting range: 0x000–0x1FF
0X000
◎
P06 Group Output terminals
P06.03
Relay RO1
output selection
0: Invalid
1: In operation
2: Forward rotation operation
3: Reverse rotation operation
4: Jogging operation
5: The inverter fault
6: Frequency degree test FDT1
7: Frequency degree test FDT2
8: Frequency arrival
9: Zero speed running
10: Upper limit frequency arrival
11: Lower limit frequency arrival
12: Ready for operation
13: Pre-magnetizing
14: Overload pre-warning
15: Underload pre-warning
16: Completion of simple PLC stage
17: Completion of simple PLC cycle
18: Setting count value arrival
19: Defined count value arrival
20: External fault valid
21: Reserved
22: Running time arrival
30
○
P06.04
Relay RO2
output selection
5
○
