INVT CHV Series User Manual

List of Function parameters
113
Function
Code
Name Description
Factory
Setting
Modify LCD Display
P3.05
ASR switching
point 2
P3.02~P0.07 10.00Hz ○
ASR
SWITCHPOIN
T2
P3.06
ACR proportional
gain P
0~65535 500 ○ ACR P
P3.07 ACR integral gain I 0~65535 500 ○ ACR I
P3.08
Speed detection
filter time
0.00~5.00s 0.00s ○
FEEDBACK
FILTER
P3.09
Slip compensation
rate of VC
50.0~200.0% 100% ○
VC SLIP
COMP
P3.10 PG parameter 1~65535 1000 ◎
PG
PARAMETER
P3.11
PG direction
selection
0:Forward
1:Reverse
0 ◎
PG
DIRECTION
P3.12
Torque setting
source
0:Disabled
1: Keypad
2:AI1
3:AI2
4:AI3
5:AI4
6:HDI1
7:HDI2
8:Communication
0 ○
TORQUE
SETTING
P3.13
Keypad torque
setting
-100.0%~100.0% 50.0% ○
KEYPAD
TORQUE SET
P3.14 Torque limit
0.0~200.0%(rated current of
inverter)
150.0% ○
TORQUE
LIMIT
P4 Group: V/F Control
P4.00 V/F curve selection
0:Linear curve
1: User-defined curve
2: Torque_stepdown curve
(1.3 order)
3: Torque_stepdown curve
(1.7 order)
4: Torque_stepdown curve
(2.0 order)
0 ◎ V/F CURVE
P4.01 Torque boost
0.0%: auto
0.1％~10.0％
1.0％ ○
TORQUE
BOOST
