INVT CHV Series User Manual

List of Function parameters
115
Function
Code
Name Description
Factory
Setting
Modify LCD Display
P5.04
S3 Terminal
function
7 ◎
S3
FUNCTION
P5.05
S4 Terminal
function
0 ◎
S4
FUNCTION
P5.06
S5 Terminal
function
0 ◎
S5
FUNCTION
P5.07
HDI1 terminal
function
0 ◎
HDI1
FUNCTION
P5.08
HDI2 terminal
function
0 ◎
HDI2
FUNCTION
P5.09
S6 Terminal
function
0 ◎
S6
FUNCTION
P5.10
S7 Terminal
function
0 ◎
S7
FUNCTION
P5.11
S8 Terminal
function
8:Pause running
9:External fault input
10:UP command
11:DOWN command
12:Clear UP/DOWN
13:Switch between A and B
14:Switch between A and
A+B
15:Switch between B and
A+B
16: Multi-step speed
reference1
17: Multi-step speed
reference2
18: Multi-step speed
reference3
19: Multi-step speed
reference4
20: Multi-step speed pause
21: ACC/DEC time selection
1
22: ACC/DEC time selection
2
23: Reset simple PLC when
stop
24: Pause simple PLC
25: Pause PID
26: Pause traverse operation
27: Reset traverse operation
28: Reset counter
29: Reset length
30: ACC/DEC ramp hold
31: Disable torque control
32~52: Water supply control
53: 3-wire jog control
54~55: reversed
0 ◎
S8
FUNCTION
P5.12 ON-OFF filter times 1~10 5 ○
Sx FILTER
TIMES
P5.13
FWD/REV control
mode
0: 2-wire control mode 1
1: 2-wire control mode 2
2: 3-wire control mode 1
3: 3-wire control mode 2
0 ◎
FWD/REV
CONTROL
P5.14
UP/DOWN setting
change rate
0.01~50.00Hz/s 0.50Hz/s ○
UP/DOWN
RATE
P5.15 AI1 lower limit 0.00V~10.00V 0.00V ○
AI1 LOW
LIMIT
P5.16
AI1 lower limit
corresponding
setting
-100.0%~100.0% 0.0% ○
AI1 LOW
SETTING
