INVT CHV Series User Manual

List of Function parameters
127
Function
Code
Name Description
Factory
Setting
Modify LCD Display
PA.26 Multi-step speed 12 -100.0~100.0% 0.0% ○
MULTI-SPEE
D 12
PA.27
12
th
Step running
time
0.0~6553.5s(h) 0.0s ○
RUNNING
TIME 12
PA.28 Multi-step speed 13 -100.0~100.0% 0.0% ○
MULTI-SPEE
D 13
PA.29
13
th
Step running
time
0.0~6553.5s(h) 0.0s ○
RUNNING
TIME 13
PA.30 Multi-step speed 14 -100.0~100.0% 0.0% ○
MULTI-SPEE
D 14
PA.31
14
th
Step running
time
0.0~6553.5s(h) 0.0s ○
RUNNING
TIME 14
PA.32 Multi-step speed 15 -100.0~100.0% 0.0% ○
MULTI-SPEE
D 15
PA.33
15
th
Step running
time
0.0~6553.5s(h) 0.0s ○
RUNNING
TIME 15
PA.34
ACC/DEC time
selection for step
0~7
0~65535 0 ○
0~7 TIME
SELECT
PA.35
ACC/DEC time
selection for step
8~15
0~65535 0 ○
8~15 TIME
SELECT
PA.36 Time unit
0: Second
1: Hour
0 ◎ TIME UNIT
PB Group: Protection Function
PB.00
Input phase-failure
protection
0: Disabled
1: Enabled
1 ○
IN PHASE
FAIL
PB.01
Output
phase-failure
protection
0: Disabled
1: Enabled
1 ○
OUT PHASE
FAIL
PB.02
Motor overload
protection
0: Disabled
1: Normal motor
2: Variable frequency motor
2 ◎
MOTOR
OVERLOAD
PB.03
Motor overload
protection current
20.0%~120.0% 100.0% ○
OVERLOAD
CURR
