INVT CHV Series User Manual

List of Function Parameters
128
Function
Code
Name Description
Factory
Setting
Modify LCD Display
PB.04
Overload
pre-warning
threshold
20.0%~150.0% 130.0% ○
OL WARN
CURR
PB.05
Overload
pre-warning
selection
0: Always detect relative to
motor rated current
1: Detect while constant
speed relative to motor rated
current
2: Always detect relative to
inverter rated current
3: Detect while constant
speed relative to inverter
rated current
0 ◎
OL WARN
SELECT
PB.06
Overload
pre-warning delay
time
0.0~30.0s 5.0s ○
OL WARN
DELAY
Pb.07
Threshold of
trip-free
230.0V~600.0V 450.0V ○
TRIPFREE
POINT
PB.08
Decrease rate of
trip-free
0.00Hz~P0.07 0.00Hz ○
TRIPFREE
DECRATE
PB.09
Over-voltage stall
protection
0: Disabled
1: Enabled
0 ○
OVER VOLT
STALL
PB.10
Over-voltage stall
protection point
120~150% 125% ○
OV PROTECT
POINT
PB.11
Over-current
protection
0: Disabled
1: Enabled
1 ○ OVER CURR
PB.12
Over-current stall
threshold
100~200% 160% ○
OC
THRESHOLD
PB.13
Frequency
decrease rate
0.00~50.00Hz/s 1.00 Hz/s ○
FREQ DEC
RATE
PC Group: Serial Communication
PC.00 Local address
1~247
0: broadcast address
1 ○
LOCAL
ADDRESS
PC.01 Baud rate selection
0: 1200BPS
1: 2400BPS
2: 4800BPS
3: 9600BPS
4: 19200BPS
5: 38400BPS
4 ○ BAUD RATE
