Goodrive100-PV Series Solar Pumping VFD Installation guidelines
8
Running
environment
condition
The installation site of the VFD should:
Keep away from the electromagnetic radiation source;
Keep away from contaminative air, such as corrosive gas, oil mist and
flammable gas;
Ensure foreign objects, such as metal power, dust, oil, water cannot
enter into the VFD (do not install the VFD on the flammable materials
such as wood);
Keep away from direct sunlight, oil mist, steam, and vibration
environment.
When the altitude exceeds 1000m but is lower than 3000m, derate
1% for every additional 100m;
When the altitude exceeds 2000m, configure an isolation transformer
on the input end of the VFD.
When the altitude exceeds 3000m but is lower than 5000m, contact
our company for technical consultation. Do not use the VFD at an
altitude higher than 5000m.
The VFD should be installed on an upright position to ensure
sufficient cooling effect.
Note:
Goodrive100-PV series VFDs should be installed in a clean and ventilated environment
according to enclosure classification.
Cooling air must be clean, free from corrosive materials and electrically conductive dust.
3.1.2 Installation direction
The VFD may be installed on the wall or in a cabinet.
The VFD needs be installed in the vertical position. Check the installation site according to the
requirements below. See Appendix D Dimension drawings for frame details.
3.1.3 Installation manner
(1) The VFDs ≤ 2.2kW support wall mounting and rail mounting.
